DX51D Hot Rolled Steel Hot Dipped Galvanized Steel Coil Galvalume

Availability:
Quantity:

Product Description

Galvalume steel is also called Aluminum-Zinc Alloy Coated Steel, Zincalume steel, aluminized zinc steel (aluzinc steel), SGLC, The galvalume metal is composed of 55% aluminium, 43.4% zinc and 1.6% silicon solidified at 600 ~C. Its whole structure consists of aluminium-iron-silicon-zinc, forming a compact quaternary crystal alloy. The surface of the galvalume steel sheet is characterized by smooth, flat and gorgeous stars, and its base color is silver white. The special coating structure makes it have excellent corrosion resistance. The normal service life of galvalume steel sheet is up to 25a, and its heat resistance is good. It can be used in high temperature environment at 315 C. The adhesion between coating and paint film is good, and it has good processing performance. It can be punched, sheared and welded. The surface conductivity is very good.


Wayne can help you choose the ideal Galvalume steel for your application based on the fabrication method and type of environment in which the steel will be used.


Product Name Galvalume steel plate/sheet
Material Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Thickness 0.12-6.00mm or customer's requirement
Width 600mm-1500mm, according to customer's requirement
Zinc coated 30g-275g/m2
Type of Coating Hot Dipped Galvalume Steel
Surface Treatment Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Standard JIS 3302 / ASTM A653 /EN10143 AISI , ASTM , DIN , GB , JIS G3302 G3312 G3321 , BS
Technique Hot Rolled / Cold Rolled
Product Application 1. Fence, greenhouse, door pipe,greenhouse
2. Low pressure liquid, water, gas, oil, line pipe
3. For both indoor and outdoor the building construction
4. Widely used in scaffolding construction which is much cheaper and convenient
Delivery Time Usually within 10-45 days after receipt of advance payment
Certificates API ISO9001-2008,SGS.BV



Z-8


Z-11


Z-10


Product Advantages

1.Corrosion resistance:When zinc is abraded, aluminum forms a dense layer of alumina that prevents further corrosion of the corrosive material inside.
2.Heat resistance:Aluminum zinc alloy steel has good heat resistance and can withstand high temperatures of more than 300 degrees Celsius.
3.Thermal reflexes:The heat reflectivity of Al Zn steel plate is very high, which is two times that of galvanized steel sheet.

4.Economical efficiency:Since the density of 55% AL-Zn is smaller than the density of Zn, the aluminum-zinc-plated steel sheet is more than 3% larger than the area of the plated steel sheet when the weight is the same and the thickness of the gold-plated layer is the same.


Package of GI coil

Standard Export Packing:

Galvanized metal fluted rings on inner and outer edges

Galvanized metal and waterproof paper wall protection disk

Galvanized metal and waterproof paper around circumference and bore protection

About the sea worthy packaging: extra reinforcement before shipment to ensure that the goods are safer and less damaged to customers.

6_看图王

4_看图王

3_看图王

Applications of Galvalume Steel coil :

1.Construction and building: roofing, interior and exterior wall panels, the surface sheet of the balcony, ceiling, partitioning walls, windows and doors, gutter, barn, sound insulation wall, etc..

2.Further processing: coating base plate.

3.Electric appliance: refrigerator; washing machine; recorder; microwave, etc.
